Using wildcards and string expressions to find objects by name

From Ciaran on the XSI mailing list, here’s a good example of how to find all light nulls whose names contain “lamp” or “light”:

oLightNulls =  oModel.FindChildren2("{*light*,*lamp*}",c.siNullPrimType)

The curly brackets {} are used in a string expression to specify a list of objects.

That String Expressions page still looks pretty much the same as it did back in 1999, when I first wrote it!

About the Selection Change Command

In the Selection preferences, there’s a Selection Change Command text box where you can type in a command to run when the selection changes.

Here are two important points about the Selection Change Command:

  1. Use the VBScript syntax to enter the command. It doesn’t matter what the current scripting language is, the preference expects VBScript (so something like Application.LogMessage( “Hello %s” % Application.Selection(0) ) will end up logging an error when you select something).
  2. The Selection Change Command is triggered when you select something in a 3D viewport. The command isn’t triggered when you select an object in the explorer.

Whoops I guess Softimage did need that file…

Awhile back, I wrote a little script that used ElementTree to parse the XML returned by GetConnectionStackInfo. I posted the 2013sp1 version of the script here.

Anyway, I was a little surprised when I couldn’t get the script to run in 2012 SAP. I was sure that it used to work, but now it was giving me this error:

# ERROR : Traceback (most recent call last):
#   File "<Script Block >", line 17, in <module>
#     connections = ET.XML(stackInfo)
#   File "C:\Program Files\Autodesk\Softimage 2012.SAP\Application\python\Lib\xml\etree\", line 962, in XML
#     parser = XMLTreeBuilder()
#   File "C:\Program Files\Autodesk\Softimage 2012.SAP\Application\python\Lib\xml\etree\", line 1118, in __init__
#     "No module named expat; use SimpleXMLTreeBuilder instead"
# ImportError: No module named expat; use SimpleXMLTreeBuilder instead
#  - [line 17]

After digging into the problem a bit, I found that the Softimage install did indeed include expat, but Softimage wasn’t finding it…because I had deleted the Application\python\Lib\ file!!! Doh.

I had deleted while investigating a problem report from a customer, and then I didn’t bother putting it back, because Python was still working in general. adds paths like %XSI_HOME%\Application\python\DLLs to the sys.path, and pyexpat.pyd is in that DLLs folder.

Scripting the creation of text objects

Here’s a little Python snippet that creates a bunch of text objects, one for each item in a list. Note the handling of multiple lines (elements in triple quotes).

names = ["Test", """Coming
Soon""", "XSI",

for n in names:
                text = Application.CreateMeshText("CurveListToSolidMeshForText", "siPersistentOperation")
                if n.find( "\n" ):
                                n = n.replace( "\n", "\\par\r\n" )
                                Application.SetValue(str(text) + ".crvlist.TextToCurveList.text.singleline", 0, "")
                Application.SetValue(str(text) + ".crvlist.TextToCurveList.text.text", "%s%s%s" % ("_RTF_{\\rtf1\\ansi\\deff0{\\fonttbl{\\f0\\froman\\fcharset0 Arial;}}\r\n\\viewkind4\\uc1\\pard\\lang1033\\f0\\fs20 ", n, "\\par\r\n}\r\n"), "")
                Application.SetValue(str(text) + ".extrudelength", 1, "")

Friday Flashback #83

Review of SOFTIMAGE XSI 1.0 from 3DWorld Magazine issue no 1, 2000.

To be honest, from the outset we were prepared to be underwhelmed by [XSI]…eclipsed as it has been by Maya [but] when you get down to it, XSI is simply a stunning piece of software and we wever very impressed

Hat tip to Daniel Brassard for kindly sending this in.

Another look at IsElement problems

I’ve had some problems with IsElement lately, so I took another look at how to work around problems with IsElement, especially when you’re using it with ICE topology. Also, a quick look under the covers at the connections in the construction stack (aka operator history).

Here’s the script I was using to print the connection stack info:

# This script works in 2013 SP1 only because it uses sipyutils
from sipyutils import si			# win32com.client.Dispatch('XSI.Application')
from sipyutils import siut		# win32com.client.Dispatch('XSI.Utils')
from sipyutils import siui		# win32com.client.Dispatch('XSI.UIToolkit')
from sipyutils import simath	# win32com.client.Dispatch('XSI.Math')
from sipyutils import log		# LogMessage
from sipyutils import disp		# win32com.client.Dispatch
from sipyutils import C			# win32com.client.constants

siut =siut()

sisel = si.Selection

from xml.etree import ElementTree as ET

prim = sisel(0).ActivePrimitive if si.ClassName(sisel(0)) ==  'X3DObject' else sisel(0)

stackInfo = siut.DataRepository.GetConnectionStackInfo( prim )
#log( stackInfo )
connections = ET.XML(stackInfo)
currentMarker =''

print "Connections for %s" % prim.FullName
for connection in connections:
		o = connection.find('object').text
		if o == currentMarker:
		if o.endswith('marker'):
			currentMarker = o
		print "%s (%s)" % (connection.find('object').text, connection.find('type').text)

The case of Error 2000 Failed creating scripting engine XSI.SIPython.1

The guy sitting next to me kept getting this Python error at startup (which meant I had to either fix his install or continue taking all the CrowdFX cases 😉

' ERROR : 2000 - Failed creating scripting engine: XSI.SIPython.1.
' pythoncom error: PythonCOM Server - The 'win32com.server.policy' module could not be loaded.
' <type 'exceptions.ImportError'>: No module named win32com.server.policy
' pythoncom error: CPyFactory::CreateInstance failed to create instance. (80004005)

This happened only with the Python installed with Softimage. We did runonce.bat. We checked that Python was in the PATH. I scoured a Process Monitor log for several hours. But no luck. After a few days off, I came back and took another look at his Process Monitor log, and I noticed that at a certain point, Softimage switched over to reading files from the system Python install (in C:\Python26). And that was the clue.

It turns out that the environment variable PYTHONHOME was set to C:\Python26. Unsetting that environment variable was the solution.

Setting PYTHONPATH to C:\Python26 also causes the same error.
